Type

FK150-11

L×W×H(mm)

2045X820X1110mm

WHEEL BASE(mm)

1350mm

GROUND CLEARANCE(mm)

160mm

WEIGHT(Kg)

125 Kg

MAX LOADING(Kg)

150 Kg

MAX SPEED(Km/h)

≧90 Km/h

BRAKE MODE(F/R)

DRUM/DRUM

WHEEL STYLE(F/R)

ALLOY

TIRE SIZE(F/R)

F: 2.75-18 防滑 R:3.25-18防滑

TANK CAPACITY(L)

13L

DISPLACEMENT(ml)

144.6mL

ENGINE TYPE

1 CYLINDER-AIR COOLED-4 STROKE

STARTING MODE

ELECTRIC/KICK

SPARKING MODE

C．D．I

CYLINDER DIAMETER*STROKE(mm)

62×49.5

MAX POWER (Kw*r/min)

8.5KW/8500 r/min

MAX TORQUE(n.m*r/min)

10.5N.m/7500 r/min

FUEL CONSUMPTION(L/100km)

2.05L/100km

LUBRICATION METHOD

FORCE AND SPLASH LUBRICATING

40HQ (CKD) LOADING QTY

175 sets

40HQ (SKD) LOADING QTY

105 sets
